| "GHE Series" EXTRUDER GEARBOX |
| |
The gear units are quite capable to transmit the high torque required for pressurising and plasticising moulding materials and also to absorb the high axial thrust load through built-in spherical roller thrust bearing. The axial bearing housing is standardised to accommodate suitable thrust bearings and corresponding output shafts with key are splined. |
| |
Range |
Power range upto 250 Kw
Reduction Ratio upto 25.6/1 |
|
|
Sizes |
From 112mm to 355mm center distance |
|
|
Type |
Single screw extruder |
|
|
Applications |
Plastic Extrusion & PVC Extrusion |
|
|
Industries |
Plastic Industry |
|
| |
|
|
| "H-Series" HELICAL / BEVEL HELICAL GEARBOX |
| |
Case hardened and Profile ground Steel Gears with inclined tooth to transmit the torque between parallel / Right Angle shafts with minimum noise. |
Range |
Power range upto 5500 Kw
Reduction Ratio range upto 650/1 |
|
|
Sizes |
From 125mm to 850mm center distance |
|
|
Type |
Helical / Bevel Helical |
|
|
Applications |
For applications > 50Kw Agitators, Conveyors, Crushers, Cranes, Larger Ball Mills, Mixers, Aerators, Fin Cooler Drives, Kneaders, Thickeners |
|
|
Industries |
Sugar, Cement, Paper, Solvent Extraction, Rubber, Steel Industry, Power Plants, Mines and Minerals, Chemical |
|
|
|
| VERTICAL COAL PULVERIZING MILL GEARBOX |
| |
Bevel helical gear units capable of taking large vertical downward thrust load. Cast Iron Case designed to absorb excess vibration during running of mill. |
| |
Range |
Power range upto 400Kw
Reduction Ratio upto 25/1 |
|
|
Sizes |
From 760mm to 1000mm center distance |
|
|
Type |
8.5 ES / 8.5 EX / 10P - (2/3 Stage) |
|
|
Applications |
Vertical Coal Pulverizing |
|
|
Industries |
Cement, Paper, Steel Industry & Power Plants |
|
|
|
|
| |
|
| |
|
| |
|
