Type  HCP : Centrifugal Pumps

Designed As Per ANSI D73.1 1974

----------------------------------------------------------------

Chemical Process Pumps

Superior Hydraulics   Extensive Coverage  Max. Interchangeability

Applications :

Virtually all chemicals, acids, alkalies, corrosive slurries, solvents, hydrocarbons etc.

Range :

Capacity : Upto 800 m3/hr.
Head : upto 230 mtrs.
Temperature : upto 2600C
Working Pressure : Upto 26kg/cm2
Speed : upto 3000 rpm
Shaft Sealing : Gland / Mech. seal

Material of Construction :

C.I., C.S., S.S. 304, SS 316, SS316L, Alloy 20, Hastalloy Model, Ni-Hard etc.

Type : HPP

Designed As Per ISO 2858 (DIN-24256) Standard

----------------------------------------------------------------

Plastic Moulded Pumps


Superior Hydraulics   Extensive Coverage  Max. Interchangeability

Applications :

Hard to handle Corrosive Acids & Alkalies Effluent Treatment Plant
Scrubbing Corrosive Gases
Electro Plating / Descaling / Pickling Plants

Range :

Capacity : Upto 120 m/hr.
Head : upto 130 mtrs.
Temperature : upto 700C for P.P.
               upto 1000C for U.H.M.W.P.E.
               upto 2000C for Teflon
Speed : upto 3000 rpm
Shaft Sealing : Gland / Mech. seal

Material of Construction :

P.P., U.H.M.W.P.E., P.V.D.F., P.T.F.E. ( TEFLON ), TEFLON-LINED, ETC.

Vertical Submerged Type Pumps
----------------------------------------------------------------

Vertical Submerged Type Pumps

Applications :

Virtually all chemicals, acids, alkalies, corrosive slurries, solvents, hydrocarbons etc.

Range :

Capacity : Upto 800 m3/hr.
Head : upto 230 mtrs.
Temperature : upto 2600C
Working Pressure : Upto 26kg/cm2
Vertical Length upto 3.5m in 2900rpm
                             upto 5.0m in 1450rpm
Shaft Sealing : Gland / Mech. seal

Material of Construction :

C.I., C.S., S.S. 304, SS 316, SS316L, Alloy 20, Hastalloy Model, Ni-Hard etc.
