POWER CHUCKS
Many reputed industries have their machine shops fitted with "JAWS" power chucks on their CNC machines, Capstan and standard lath machines too.

ADVANTAGES
1. Clamping and unclamping time is saved.
2. Higher rate of material removal is possible.
3. Keying time is saved; hence operator fatigue is also eliminated.
4. Clamping and unclamping force can be uniformly controlled by adjusting
    the air/hydraulic pressure.
5. Chuck can be opened and cleaned on the spindle itself since 'Jaws'
    Power Chucks are front opening.
6. The self-locking system provided ensures a firm grip on the component,
    thus preventing accidents in case of power failure or hydraulic/pneumatic
    supply failure.

TECHNICAL FEATURES

Range : Available in 2, 3, 4 & 6 jaws

CLOSE POWER CHUCKS	POWER OPERATED HOLLOW HGH SPEED CHUCKS

These chucks were earlier manufactured by M/S Batliboi & Co. in collaboration with Reishauer of Switzerland. These chucks are uniquein design and accuracy with no scroll, no cams but with screw, rack and pinion drive.
LONG LASTING ACCURACIES, IMMENSE CHUCKING POWER, MINIMUM OPERATORS FATIGUE .... these are but a few of the combined advantages the JAWS PRECI CHUCKS offers you

All the parts held on chucks and turned require machining in two or more set-ups. It means
Elaborate fixtures involving references and high accuracies Loss of concentricity at various stages Inaccuracies involved in mounting Time lost in mounting each component, number of times Loss of machine hour in set ups, set up approvals and rejections
This is a new concept of machineing components without the drawbacks mentioned above. We have to make a pair of holders suitable for your part, fix them on mounting pads, hold the part in the chucks, set all the tols required for all the faces, and start machining, after first face is completed.
Pull clutch lever Turn the part partly with hand Release the lever Continue to turn the part until you hear a click assuring that the part has indexed exactly by 90 or 180 degrees (provision can be made for different angles also) Clamping can also be done with pneumatic/ hydraulic cylinder

Jaws & Spares manufactured to suit Chucks, such as PRECI, ( previously known as SRM), TURNO, SECO, SONALKAR, UNNAT, SUPER ZITHER, BONNET, PARCO, OSTER, and 3 jAW & 4 jAW CHUCKS of all sizes as well as other brands as per sample or drawings.

	Soft Jaws and Hard Jaws for NC, CNC and machining center machine is our speciality. Base Jaws for imported quick change chucks of any make are manufactured by us. We make 5 Jaws Power Chucks as well as 12 Jaws Manual Chucks

ROTARY CYLINDERS

These high speed Rotary Cylinders with or without through bores are used for actuating Power Chucks/ Collect Chucks on any machine. The compact design of the cylinders makes for low mass and moment of inertia. Hardened & ground steel components give long working life under normal operating conditions.
HYDRAULIC ROTARY CYLINDER	PNEUMATIC ROTARY CYLINDER
Special Features : The design of cylinder is such that the distributor shaft rotates on special bearing facilities the cylinder to be started at very high speed.

Adaptor for Cylinder Back plate for Chucks Drawbar Partial hollow system including Adaptor for CYL Draw tube
