We J. J Arc Control System got established in the year, 1994, and are successfully led by Mr. J. Manne. His extensive industry experience has guided us through the years to emerge as a fast developing company in the field of manufacturing machines. With over one decade of experience in this field we are able to satisfy the requirements of our clients. |
|
Our comprehensive range of products include spot welding machine, co2 welding machine, CD welder, arc welding transformer, seam welding machine and stabilizers. With our range of efficient machines we have brought about a revolution in the field of machine production. Our line of products is of world-class quality, renowned for consistent quality, reliability, efficiency, safe to use and easy maintenance. |
| |
We have attained the SSI membership with our profound range of products. To further ensure clients about our products we are also in process to attain ISO certification for our precision engineered products read more.. |
|
| |
|
| |
| |
Co2 Welding Machine |
|
| Our CO2 welding is extensively used in the industries from where this equipment has been appreciated for its quality. Being highly reliable and safe in use, we assure a great quality. Following are its technical specifications, which show its excellence in working: |
| |
Model |
Units |
JJM 200 |
JJM 300 |
JJM 400 |
| Welding Current Range |
Amp |
30-220 |
30-300 |
40-400 |
| Max cont. Welding Current at 60% duty cycle |
Amp |
220 |
300 |
400 |
| Current at 100% duty cycle |
Amp |
160 |
215 |
285 |
| Open Circuit Voltage |
V |
18-35 |
16-48 |
20-54 |
| Input Supply |
AC V |
415V, 3 Phase |
415 V, Phase |
415 V, 3 Phase |
| Continuous/ Max Input |
KVA |
6.6 / 9 |
10.3/14.4 |
17.9/25.2 |
| Switch Fuse |
 |
TP -20 |
TP-30 |
TP-40 |
| Insulation Class |
 |
'F' Class |
'F' Class |
'F' Class |
| Cooling No of Rollers |
 |
Forced Air Cooled 2 |
Forced Air Cooled 2 |
Forced Air Cooled 2 |
| Max diameter 1 Steel 2 Aluminum |
mm mm |
0-8-1.2 1-1.2 |
0.8-1.6 1-1.6 |
0.8-2.4 1-2.4 |
| General Welding Torch Cooling |
 |
Gas |
Gas |
Gas |
| Hose Length |
Mtr |
3 |
3 |
3 |
| Max Current Capacity |
Amp |
220 A |
300 |
400 |
|
|
|
| |
| |
CD Welder |
|
We are offering a vast range of CD welder, which provide highly rated performance. These are widely demanded by light and heavy fabrication workshops, shipbuilding & auto industries and many more. This equipment operates on the principle of capacitor discharge stored energy (½ cv²) is discharged into weldment via pulse Transformer within for milliseconds. Therefore, we get perfect, clean and undistorted weld joint. Our C.D Welders are designed especially for excellent performance and have successfully developed a long-term relationship with the customers. Following are some of its salient features: |
| |
- Input power requirement is much less than conventional Resistance Welding machines.
- Welding of similar or dissimilar metal possible
- Weld Joints are clean and without deforestation
- Input Voltage fluctuation does not affect weld quality
- No requirement of water cooling
- No cause of wear and tear of welding electrodes and fixtures
- Machines can be run on Genset
- Very easy handling of jobs because they don't get heated much
|
|
|
| |
|
| |
| |
