Heat Shrinkable Polyester Woven Tapes
|
Service Or Armor Wrap For Form Wound Coils |
Hot Knife Slit Edges - Woven For Greater Yarn Stability And Conformability
For Service or Armor taping form coils
and other electrical coils where excellent
conformability is required. The shrinking of these
non-fraying tapes following varnish treatment enables
coils to be produced with maximum resin retention and a
minimum of void content. For this reason these tapes are
especially adaptable to VPI systems and also wherever
mica wrappers are used. |
|
|
| |
Silicone Rubber Fiberglass Sleeving (FRS)
|
|
Silicone Rubber fiberglass sleeving (inside fiber and outside rubber) is class H high voltage withstanding sleeving, which is widely used for class H motor, electrical appliance, heating equipment and special lighting fixture. |
Diameter : 0.5-----30mm |
Length : 1 meter per pc |
Breakdown voltage : 4000V |
Class : H |
Colour : White, black, red Etc. |
|
|
|
| |
Fireproof Mica Paper Tape
|
|
Fireproof mica paper tapes possess excellent flexibility at normal condition and a little sticky. They are easy to wind up the conductor of cable tightly, having high mechanical strength, high mica content and excellent electric performance. The security cables wrapped with fireproof mica paper possess the reliable performance of flame-resistant in conformity with the requirement of The characteristic of Flame resistant for cable, IEC publication 331 and possess the performance of excellent waterproof. |
|
|
| |
|
|
This fabrics include various kind of electrical grade glass fabric of which the surface has been processed with chemical methods. The products are used as the base material of copper clad laminate. They are produced with various kinds of automatic precision equipment, such as Wraping-sizer, Rebeamer, Air Jet Loom; Finish Machine etc. |
|
|
| |
| |
|
| |
