MANUFACTURERS OF
HYDRAULIC KEYWAY MILLING MACHINES & SELF CENTERING VICE

WE ALSO UNDERTAKE ALL TYPE OF TOOL ROOM JOB WORK
AND CYLINDRICAL GRINDING,
SPECIALALIST IN KEYWAY, SPECIAL EXTERNAL AND INTERNAL KEYWAY

Company


We manufacture Hydraulic Keyway Milling Machines, Minimaster 2220 and Minimaster 2230 for Milling Keyways on Shafts from 10 mm dia to 300 mm dia.Keyways Length ranges from 300 mm to 600 mm. Besides, we also manufactuere Self Centering Vices in 4 Modles and All Types Ball Bearing Centres suitable for MT Tapers.


Products




HYDRAULIC KEYWAY MILLING MACHINES

HYDRAULIC KEYWAY MILLING MACHINES

KWALITY’ AN EXCELLENCE


A Mini Master from ‘Kwality’ comes with a passionate Technology MINI MASTER 2220’ with its Robust Appeal Is not only Capable of cutting deep in to surface but surprises every user with us unimaginable accuracy & surface finish too along with extremely neglegible tool breakage.


BODY & SLIDING HEAD


Manufacturing a Machine of Excellence that allows Complete Value for Money. We are at service to the Customer & user this ‘Mini Master 2220’ made out of close grain heavily ribbed cast iron casting toensure vibration free opreation.


SLIDING SLEEVE


Manufactured out of Seamless Tube Located and Slides in Sliding head into closely Honed Bore.Cross slide beneath the vice can be used fov woodruff key way cutting.


SPINDLE


‘MINI MASTER 2220’ Comes with a Spindle for holding cutting tools. It has a highly durable and maintenance free features adding firmness orginaly and stiffness is the two bottom and one top, Single Row Ball bearings originated from either FAG, Timken or SKF. Noiseless Spindle runs at accuracy within 5 microns.

HYDRALIC POWER PACK & COOLENT TANK


Both these Power Pack and Coolent Tank are located in Bottom Stand. Power Pack can generate 35 Kg.Cm2 with help of 1HP Motor, along with pump having capacity of 4 LPM.


Specifications

FOR 2220
FOR 2230
Capacity
2 mm to 20 mm dia of cutters 2mm to 30 mm dia of cutters
Transverse
Max.Upto a stroke of 300mm either side Max.Upto a stroke of 300mm.Modified upto 600 mm
Spindle Motor
2 H.P. 3 H.P.
Spindle Nose
Holds E 40 Collets upto 20 dia Holds E 40 Collets upto 30 dia
Speed Range
360 to 1500 RPM 360 to 1500 RPM
Weight Approx
1200 Kg. 1450 Kg.
Machine Dimensions
( L X B X H ) 800 X 900 X 1800 ( L X B X H ) 800 X 900 X 2000
Component Position Accuracy
Can be Set on Self Centering Vice within 0.010 microns Can be set on Self Centering Vice within 0.010 microns
Repetability
within 0.010 microns within 0.010 microns
Hydraulic Gadgets
Yuken Brand Yuken Brand

  This Machine Can be use of Manually

Automatic sprindle movement, incremental Control progamed with rapid return (Additenally provided if required)
