• Pressure Gauges
• Bimetal Thermometer
• Pressure Transmitter - Model S-10 / S-11
• Temprature Transmitter Model T -19
• Differential Pressure Gauges
• Flanged Process Connection Model 990.27
• Temperature Sensores
• Humidity & Temperature Transmitters
• Humidity & Temperature Indicator
• I/P Transducer : 500 FC
• Diffrential Pressure Switches
• Differential Pressure Switches
• PID Controllers
• Process Scanner / Data Logger
• Universal Calibrator
• Signal Isolator
• Thermometer
• Diffrential Pressured Transmitters |
|
|
|
|
|
|
|
The Company was started with an objective to provide engineering products and complete solutions for Instruments for all types of PRESSURE, DIFFERENTIAL PRESSURE, TEMPERATURE, HUMIDITY, LEVEL, PH, CONDUCTIVITY, TIME, RPM , COUNT, CONVERTOR, DATALOGGING & INSTRUMENTATION & ELECTRICAL PANELS. Some parts of Pneumatics & General purpose Instruments based on the latest and best possible technology available in the world.
The Company is registered under Indian Companies Act. |
|
|
|
|
|
|
|
15 E, 5th Floor, Sagar Corner Building, Near Nashik Phata, Kasarwadi, Pune - 411034.,
Tel No.: + 91- 20- 46760186, 27111582, Fax No.: + 91 - 20- 27111583,
Mobile No.: + 91 - 94220 01196, 99607 77654
Email.: [email protected] |
|
|
|
|
|
|
PRESSURE TRANSMITTER· MODEL S·10 I S·11 |
|
|
|
|
WIKA GMBH make
Compact in Size
Ranges from - 1 to 600 bar
SS body & Wetted Parts SS316L
4 - 20 mADC 2 Wire Output
Supply: 10-30 VDC
Accuracy: ≤0.25%
Zero/ Span Adjustments
Temperature Limit - 30 to + 100°C
½ ," BSP (M) Bottom Connection |
|
S-11 : Same as But Flush Diaphragm Type |
Pressure Transmitter having accuracy of 0.125% are available |
Intrinsically safe models available for FP Area |
|
|
|
|
|
TEMPERATURE TRANSMITTERS· MODEL T ·19 |
|
|
|
WIKA GMBH make
Configurable ranges, Head mounted or Rail mounting type.
Input: PT1 OORTD or Thermocouples (Please specify)
Output: 4 - 20 mA (2 wire)
Supply: 10 - 30 VDC
Fault signal for sensor burnout
and sensor short circuiting.
Compact in size at reasonable price
Accuracy: + 0.5%
Zero / span adjustment available |
|
|
|
|
|
|
|
|
