INTEGRATED ENGINEERS


Hot Water/ Dairy Boilers, Non-IBR Steam Boilers, Water Softners, Hot Air Generators, Thermic Fluid Heater, Waste Heat Recovery Systems, Automatic Pressure jet Burners



Manufacturers of : ( OIL / WOOD FIRED )

• Hot Water/ Dairy Boilers , • Non - IBR Steam Boilers, • Water Softeners, • Hot Air Generators, • Thermic Fluid Heater, • Waste Heat Recovery Systems & Automatic Pressure jet Burners, • Heat Treatment Furnaces


Company Profile

We heartly welcomes you in INTEGRATED ENGINEERS The Energy Group, and want to help you for your industrial solutions like various heating equipments and tailor made systems.

We are engaged in manufacturing of industrial boilers and other systems for conservation of energy.
Our confident Engineering staff and skilled man power is always eager to help you for your needs.

The factory is located in the industrial area of Miraj M. I. D. C. near District City Sangli.

OUR PRODUCTS
• Non - IBR Steam Boilers
• Hot Air Generators
• Thermic fluid Heaters
• Hot water / Dairy Boilers
• Waste Heat Recovery Systems

Automatic Oil / Gas Burners.

 Turnkey Solutions in Energy Field.
OUR MOTTO
Customer satisfaction by Engineering excellency in design to give.
Fuel Efficient
Optimally Economic
Safe & Reliable
User Friendly
Environment Friendly
Products & Systems

Products

Manufacturers of : ( OIL / WOOD FIRED )
• Hot Water/ Dairy Boilers,
• Non-IBR Steam Boilers,
• Water Softners,
• Hot Air Generators,
• Thermic Fluid Heater,
• Waste Heat Recovery Systems & Automatic Pressure jet Burners

HIGH EFFICIENT :- 90% On Oil / Gas & 87% Agro fuels.

Agro fuels

1. ECOSTEAM : - (No any IBR Certification Required)
Type :- 3/4 Pass vertical Coil type construction
Capacity :- 100Kg/hr. to 850 Kg/hr.
Working Pressure :- up to 17.5Kg/cm2 and more for special designs.
Fuel :- H.S.D / L.D.O. / F.O. / Gas / Agro waste.
Efficiency :- 90% on N.C.V. of fuel.
Heat Recovery : Economizer or Air pre heater Unit
Orientation :- Vertical / Horizontal.
Applications :- Pharmaceutical / Chemical / Rubber Industry Food industry / Dairy

 ENGINEERING EXCELLANCY BY DESIGN
2. AQUATHERM :- (Replaces IBR Formalities of Steam of Boilers.)

ENGINEERING EXCELLANCY BY DESIGN

Type :- Shell & Tube / Coil type
Capacity :- 100000Kcal/hr to 1200000kcal / hr.
Temperatures available :-
upto 95-1000C in atm pressure & up to 1400C in close loop system.
Fuel :- H.S.D. / L.D.O. / F.O. / Gas / Agro waste.
Efficiency :- 9% on N. C. V. of fuel.
Heat Recovery Unit :- Water pre heater / Air Pre heater
Orientation :- Vertical / Horizontal
Application :- Dairy / Hotels, Dying industry / Textile industry.
  SMOKELERS, EFFICIENT COMBURTION TO CONSERVE ENERGY & ENVIRONMENT.

  3. AIROWARM : (Saves over electrical heating loads b7 @ 80%)

AIROWARM

Type :- Direct / Indirect heating type
Capacity :- Up to 1500000Kcal/hr in direct & up to 800000Kcal/ hr in indirect type.
Temp. available :- up to 8000C in Direct type & up to 4000C in Indirect Type.
Fuel :- H.S.D. / L.D.O. / F.O. / Gas.
Efficiency :- @ 100% nearly in Direct & 87% in Indirect.

  4. OIL-O-THERM :- (Replaces Electrical Heating Systems by Saving over 50%)

OIL-O-THERM

Type :- Coil Type / Jacket type
Capacity :- From 100000Kcal/hr
Temp available :- upto 4000C
Fuel :- H. S. D. / L. D. O. / F. O. / Gas / Agro waste
Efficiency :- 90% on N.C.V. of fuel
Orientation :- Horizontal / Vertical
Applications :- Jack Heating process, Chemical
Pharmaceutical

  5. OIL BURNERS

OIL BURNERS

Type :- Pressure jet, Automatic, Modulating.
Capacity :- 100000Kcal/hr to 1500000kcal/hr
Fuel :- H.S.D. / L.D.O. / F.O. Kerosene / Gas.
Efficiency :- 93% on N.C.V. of fuel.
Combustion :- Smokeless & eco friendly
Orientation :- Horizontal / Down firing type & inclined.

OIL BURNERS



Contact Us



INTEGRATED ENGINEERS

Plot No. 45 & 46, Sanjay Industrial Estate,Co - Op. Society Ltd., Madhavnagar, Tal. Miraj Dist. Sangli - 416416, Maharashtra, India

Tel. No.: (Office) +91 - 233 - 2310295, 2310296   (Factory) +91 - 233 - 2344625.

(M) : +91 - 98601 61015, 94232 13913




Website : www.indoboilers.com, www.foodprocessingmachine.co.in
