UNIVERSAL TESTING MACHINE
|
| Universal Testing Machine to determine properties of tensile and elongation as per ASTM D – 638/ D 882, flexural as per ASTM D - 790 and compression as per ASTM D – 695 of unreinforced and reinforced plastics. |
Computerised Twin Screw
Dual Channel Universal Testing Machine – Higher version.
|
|
Specification :
Load capacity : up to 1000 kg*.
No. of load cell : Two.
Cross Travel : up to 1000 mm*.
Horizontal day light : 450mm*.
Speed : Variable between 2mm/minute
to 500mm/minute.
Paint : Powder coated.
Power : 230 Volts, 50Hz, single phase.
Direct display and printout through microcontroller : Numeric test report consisting values of Peak load, Break load, Elongation at peak load, Elongation at break load, Tensile strength at peak load, Tensile strength at break load, % elongation at peak load, % elongation at break load could be viewed on the micro controller and printout could be obtained by directly attaching a dot matrix printer to the equipment.
|
| Graphic display and printout through PC : In addition to the above reports, further values like Young’s modulus, Yield load, Yield stress, Flexural stress, Flexural modulus and Load Vs Elongation graph could be obtained by attaching a printer to the PC. Similarly average value and standard deviation could be obtained by merging different tests. |
|
|
| --------------------------------------------------------------------------------------------------------------------------------------------------- |
| | | | | | | | | | | | | | | | | |
|
| |
|
|
