300 Tube filling per minute (CREFIL 300)

DESCRIPTION :- The machine is sturdy, Compact in design and simple in operation , It consists mainly of positive Geneva mechanism linked to intermediate moving of chain with 24 no,s interchangeable nylon tube holder and carrier for different tube size , One ss filling syringe pump with Teflon piston , One ss filling nozzle connected to small pneumatic string cutter device for control of tailing , NO TUBE- NO FILL device to bypass empty pocket [absent of tube ] in ONLINE , One 30 kg ss hopper for paste / ointment , One ss block attached to hopper and intricate positive cam and cam assembly closed in elegantly ss cabinet . Filled, Sealed and code stamped tubes are ejected automatically on a stainless steel chute; filling assembly is very easy for cleaning or for change over to other product. SALIENT / STANDARD FEATURE OF CREFIL 60 1] Sturdy & compact design suitable for size tube 12 mm to 50 mm diameter & 70 mm to 200 mm length also spare available for changing volume of cream / ointment / paste from 5 gm to 250 gms .
2] Online NO TUBE –NO FILL system is attached in the machine.
3] The machine available in semi and complete automatic.
4] The filling is achieved by positive suction and positive pressure to discharge cream /     ointment / paste with accuracy of 00.02 + / - mg.
5] To avoid dripping / tailing, pneumatic string cutter device is provided in the machine.
6] Operation of tube pressing, first fold, second fold, batch numbering & ejection, all      these operations have separate station.
7] Digital product counter is attached in the machine.
8] Same machine can be used for filling tin, jar etc by changing nylon holder & small      modification. OPTION AVAILABLE ON TUBE FILLING MACHINE AT EXTRA COST 1]      Jacketed hopper having 1kw heater, digital temperature control arrangement.
2] SS stirrer assembly [15 to 25 RPM] with scrapper blade, base flapper.
3] Attachment for cleaning of tubes by vacuum system for specific requirement.
4] Automatic feeding of tubes in the tube holder, with two tube loading cassette.
5] Photocell device for orientating eye mark print of tube.
6] Extra fold on tube like 3rd fold on normal 2nd fold or 3rd fold reverse side on normal     2nd fold. POWER CONSUMPTION 1] MACHINE MOTOR: - 1.0 hp , 1440 rpm , 440     vac, 3 phase motor along with control panel.
2] STIRRER MOTOR: - 1.0 hp , 1440 rpm , 440 vac , 3 phase motor.
3] TUBE CLEANING SYSTEM: - 0.25 hp ,1440 rpm , 440 vac , 3 phase motor , with      vacuum pump.
4] SS JACKETED HOPPER: - 1 kw heater, with thermostatic controlling from 30 c to      100 c. TECHNICAL DATA 1] Single Head: - Linear type tube filling & sealing machine      [Model CREFIL 60]
2] Out put:- 50 to 60 tubes per minute , it also departs on volume & material viscosity.
3] Filling volume:- 3gm to 30 gm [ to fill above 30 gm extra attachment can be done ]
4] Tube diameter: - 12 to 50 mm diameter.
5] Tube length: - 70 TO 200 mm length.

DIMENSION OF MACHINE
