• Capacitor Discharge Stud Welder


Functional Description
Capacitor Discharge Stud Welding
* extremely low penetration depth of approx. 0.1 mm
* suitable for thin walled sheet metals with a minimum thickness of 0.5 mm
* no traces of welding such as pressure marks, disclouration or deformation are visible on sheet metals, even if the surface has been plastic - laminated or electroplated
* suitable for all stud welding tasks where the decorative appearance of the visible side has to be retained.
Capacitor Discharge Stud Welder
Description: The SCD - 01 Pin / Wire is suitable for Both Battery & mains operations. Thermocouple wire.
Welding range: Up to Dia. 1.5 mm. Thermocouple wire.
Power Source: Capacitor 15000 uf
Charging Voltage: 20 V - 96 V
Mains Supply: 230 V - 50 Hz - 5 Amps.
Battery: 12 V & 4 Ah.
Dimensions: 230 X 180 X 170 (L X W X H)
Weight: 8 Kg.

• Capacitor Discharge Stud Welding Gun


Description
The CDP - 01 Stud welding gun welds studs with ignition tip accurately on scribed center marked surface by spring force. Injection moulded fully insulted light weight plastic body.
Welding range Studs & Pins from m 3 - m 8 or Ø 2 - Ø 8 mm & 6-35 mm. in length.
Material Steel, Stainless Steel, Brass & Aluminium.
Welding & Control Cable 5 met. Highly flexible
Base Pitch Circle Ø 38 mm.
Weight 800 Gms. ( Without Cable )
Welding Gun

• Drawn Arc Stud Welding Equipments


Description The SW - 12 Stud Welding Controller is an attachment for Manual Metal Arc Welding rectifier to execute Drawn Arc Stud Welding
Welding range M 6 - M 12 & upto 100 mm long studs.
Welding Rate Up to 25 Pcs / Min
Welding Material Low Carbon Steel, Stainless Steel
Standard Gun DAP - 03
Welding time 0 - 1400 m/sec
External Power 600 Amps 80V D.C.
Source Constant
  Current type MMA
  Welding Rectifier
Input supply From MMA rectifier 80 V.D.C. 600 / 800 Amps.
Dimensions 460 X 290 X 545 (L X W X H)
Weight 25 Kg.
Drawn Arc Stud Welding Equipments

• Drawn Arc Stud Welding Gun


Functional Description
Drawn arc stud welding
* penetration depth from approx. 1 to 3 mm
* application on sheet metals with a minimum thickness of 2 mm
* standard drawn arc stud welders are also suitable for operation with shielding gas
* different process variants can be selected depending on the respective cases of application
* generation of high-quality weld joints
* especially suitable when high demands relevant to safety regulation are made on the welding quality.
* tried and tested procedure for structural steel engineering, mechanical engineering & ship buidling etc.
Drawn Arc Stud Welding Gun
Description The robust DAP - 03 Stud Welding gun has been especially designed to meet the hardest operating conditions & requirements the length adjustment system is suitable for differencing stud length.
Welding range Studs & Pins from M 6 - M 16 or Ø 6 - 16 mm.
Welding Process Drawn arc welding
Welding & Control Cable 5 met. Highly flexible
Total length with ceramic fearrule 200 mm
Weight 1.30 Kg. (Without Cable)
• Stud Welding Consumable

Low Carbon Steel Studs
*

Low Carbon Steel Studs
Dia 8 mm to Dia. 13 mm Pins Suitable for boilers.
Threaded Studs M8 to M20.
SS 304 - 310 Pins. Dia. 8 mm to Dia. 12 mm
Shear Studs suitable for construction work
Ceramic Ferrules suitable for 8 mm to 20 mm Dia. Studs

MATERIAL T.C. AVAILABLE ON REQUEST


Capacitor Discharge Stud Welder Capacitor Discharge Stud Welding Gun
Drawn Arc Stud Welding Gun Drawn Arc Stud Welding Equipments
Stud Welding Consumable
