Chemical Plant Machinery & Equipments, Planetory Mixers, Reactors, Reaction Kettles, Heat Exchangers, Plate Heat Exchangers, Ball Mills, Ribbon Blenders, Filter Nutsches, Calrifiers, Distillation Columns, Scrubbers, Seperators, Storage Tanks, Flakers, Rotary Vacuum Dryers, Screw Conveyors



Sunrise Process Equipments was founded in 1998 by Mr. Nilkanth Vyankat Chaudhari for fabrication of all kind of Equipments used in industries like Pharmaceuticals, Dyes, Dye Intermediates, Polyester, Effluent Treatment, Organic & Inorganic production units and all other Chemical Equipments.


We have a team of young, dynamic & qualified technocrats with around 36 years of varied experience in the field of equipment design and manufacturing, structural fabrication, erection, piping, site storage tanks and other related works. We also carry out surface linings such as lead bonding, PP/FRP lining, acid proof brick lining, rubber lining etc.

Products :

Planetary Mixer

Planetary Mixer
For the processing of sensitive & hazardous heterogeneous compositions containing low to medium viscosity resins/binders & various dried particulate fillers having different particle size ( less than 1 micron to 300 micron) under high vacuum. Intimate mixing of these ingredients is must to ensure uniform mix. End of Mix viscosity to these compositions may vary from 50 poises to 80000 poises at 25°C. For removal of moisture & occluded gas / air from high viscosity composition, application of high vacuum of 0.1 mm of Hg is necessary during mixing. For very viscous compositions initial circulation of hot water through mixer jacket is essential and to avoid sudden rise in viscosity after addition of curing agents cold water circulation through jacket is required. The Planetary mixer unit consist of a Mixer, bowl with trolley, hydraulic drive unit, remotely operated control system with PLC & SCADA along with power back up system for PLC & close circuit camera & color Monitor for remote viewing, during Mixer Operation.


Rotary Vacuum Drier

Rotary Vacuum Drier
The drying in a rotary vacuum dryer is a batch operation under vacuum. It is possible to dry heat sensitive materials at well below boiling points of water and solvents. Drying time depends on material being dried, amount of solvent or water to be removed, desired final moisture content, permissible jacket temperature etc. The dryer is available in sizes ranging from 100 liters to 20,000 liters gross volume. The volume of wet material loaded into the dryer is usually restricted to 40-45% of gross volume.


Storage Tank

Storage Tank
We provide full customization on our storage tanks as per the specifications and requirements of the client. All the raw materials are used depending on usage of the tank and also as per client’s input. These tanks are corrosion resistant and easily withstand various temperature fluctuations and variations. These tanks have a wide demand in various processing industries because of them being highly qualitative at cost effective prices.

Flaker
Flaker
Flakers are used for solidifying molten material. After processing on flakers, the material forms films or easily handled flakes and is further processed or packed into containers for transport. A great advantage of flakers is that they offer a continuous process. The hot material is applied to the cooling drum by direct immersion into a trough, or indirect immersion using doctor/applicator rolls. The molten liquid is cooled on the cooling drum and after a partial revolution; the cooled and solidified product is removed by a scraper in the form of flakes or film.

MORE INFO...
