Vacuum Cleaner, Industrial Vacuum Cleaner, Vacuum Cleaners, Mini Vacuum Cleaners, Max Vacuum Cleaners, Side Channel Vacuum Pumps, Multistage Vacuum Pump.
|
|
|
Blowtech Vacuum Cleaners are designed for industrial purpose and are used in various fields like Engineering, Textile, Food, Pharma, Wood Working, Chemical, Plastics etc. Powerful continuous suction is created by vacuum pumps of cast aluminum construction with capacities ranging from 1.5 Kw to 5.5 Kw. Hence these are continuously rated and can be used for 24 hrs/day without interruption. For higher capacities beyond 5.5Kware available on request. |
| |
|
|
Commercial Vacuum Cleaner
|
|
These are single phase machines for intermittent & light duty applications. These are ideally designed where in heavy machines cannot be used due to their movements & portability issue. These have universal vacuum motors ( brush type ) which are very compact that make these machines light weight & compact. These are various cleaning attachments to suit commercial as well industrial environment.
|
|
|
Dust Extractors
|
Applications
Blowtech Dust Extractors have wide applications in various machines/industries. Viz:
Surface Grinding / Tool & Cutter grinding Buffing machines Wood working machines Carbon dry powder collection Packaging machines etc.
Advantages
• Totally maintenance free
• High cleaning efficiency
• Continuous rating
• Compact design with a custom built hood
• Easy to operate
• Provides clean working condition thus increases the operator efficiency & prolongs equipment life |
| |
Principle of operation
The dust generated is sucked by the air stream of suction blower through slit hood. The subsequent cloth filter retains the fine particles. The filtration system is based on fabric, suspended from a manual shaker mechanism to relieve filter clogging. Filtration can be provided as per application.
Custom built designed hood can be provided to have optimum efficiency. |
|
Chip Extractors
|
| |
|
| |
Chip extractors most economical & effective solution to your dust problems. Chip or dust collected is transferred by a heavy duty steel fabricated fan. These extractors are available in stand alone option or on trolley mounting depending on requirement. The ingeniously contrived positioning of the dust collecting hood catches the dust catapulted upwards in its complete scattering area. Whenever, Dust different locations, a portable dust & chip collector is the most economical answer. All portable units with cyclonic separators have exchangeable filter systems for use with a simple filter bag. Filtrations Options other than filter bags such as Cellulose Pleated filters & Hepa filters are available on request. |
| |
Application :
a. For Extraction and disposal of dust produced by machinery, directly at source.
b. For Extraction and disposal of car exhaust fumes in automotive workshops.
c. Extraction of stale air and supply of fresh air for working operations (e.g. welding) in pits, tanks or other insufficiently ventilated confined area.
d. Extraction of dust in small sand blasting cabins.
e. Use as conveyor blower for granulated materials, etc., ON WOOD WORKING MACHINERY. |
|
| |
