Features
* Suitable for torsion & twist tests on various
   metal rods & flats.
* Torque measurement by Pendulum
   Dynamometer system.
* Auto torque selector to adjust torque ranges.
* Geared motor to apply torque to specimen
   through gear box.
* Autographic recorder for relation between
   torque & angle of twist.
* Accuracy + 1% of the true torque

Compression Testing Machine

Features
* Straining at variable speeds to suit a wide range of materials.
* Various models - Max. capacity from
50 to 500 tf.
* Wide range of standard & special
accessories including load stabilizer.
* Loading accuracy well within ± 1%

Manual Model Broaching Machine ( Hand Operated )

Manual Notch Cutting Machine :
Robustly constructed machine cuts the notches by means of a specially designed multi-toothed broach, which is drawn across the specimen by self - push of rotating hand wheel.

A simple hand-vice for holding the specimen is built on to the machine. The tooling includes the adjustors & end stop necessary to ensure that notch-depth & positions are correctly set. The approx. weight is around 35 kg.

The machine dimension (Approx.) 210mm X 210mm X 1050mm.
