| 1) Takisawa makes VMC: Very Good VMC with following specifications. |
| |
|
Table Size (W x L): 900 mm x 410 mm. |
|
Max. Table load: 400 Kg. |
|
X Stroke 760mm, Y Stroke 415 mm, Z Stroke 415 mm. Rapid Traverse rate - 12 Mtrs. |
|
Spindle : NT - BT 40, RPM - 7000, Power - 7.5 KW. |
|
24 Tool ATC. |
|
CNC System : Fanuc 0M. |
|
| |
| 2) Cellular Concept makes VMC : Very Good VMC with following Specifications : |
| |
|
Table Size (W x L) : 610 mm x 737 mm. |
|
Max. Table load : 400 Kg. |
|
X Stroke 610 mm, Y Stroke 430 mm, Z Stroke 460 mm. Rapid Traverse rate - 20 Mtrs. |
|
Spindle : NT - BT 45, RPM - 6000, Power – 15 HP. |
|
CNC System : Fanuc 0M. |
|
| |
| 3) Mori Seiki make CNC Lathe Model TL3 : Very Good CNC Lathe with following specifications : |
| |
|
Maximum Turning Dia. : 350 mm. |
|
Maximum Distance Between Centers : 550 mm. |
|
Spindle RPM - 1000, Power - 22 KW. |
|
Hydraulic Chuck and Hydraulic Tailstock. |
|
8 Station Hydraulic turret. |
|
CNC System : Fanuc 6M. |
|
|
| |
| 4) Mitsui Seiki Make Horizontal Machining Center : Completely Re conditioned machine with Following specifications : |
| |
|
Pallet Size 630 x 630. |
|
With 4th Axis. |
|
Max Load : 1500 Kg. |
|
With ATC & APC |
|
Spindle Nose Taper BT 50. |
|
Spindle RPM 50 – 2500, Power 15 KW. |
|
CNC : Fanuc 6 M. |
| |
|
| 5) HMT make VMC : VTC 800, Very Good VMC with following specifications. |
| |
|
|
Table Size (W x L) : 1220 mm x 635 mm. |
|
Max. Table load : 1500 Kg. |
|
X Stroke 1150mm, Y Stroke 530 mm, Z Stroke 500 mm. Rapid Traverse rate - 12 Mtrs. |
|
Spindle : BT 50, RPM – 0-3000, Power - 7.5 KW. |
|
24 Tool ATC. |
|
CNC System : Sinumerik. |
| |
|
| 6) IKEGAI make CNC Lathe /Turn Mill Center : |
| Reconditioned CNC Lathe with following specifications : |
| |
|
|
Maximum Turning Dia. : 850 mm. |
|
Maximum Distance Between Centers : 1450 mm. |
|
Spindle RPM : 20- 2000, Power - 30 KW, Nose taper A2-8. |
|
Hydraulic Chuck and Hydraulic Tailstock. |
|
12 station Hydraulic turret. |
|
|
|
| |
7) PMT Turning Center |
|
With Hydraulic Indexing chuck. |
|
Suitable for machining of UJ Crosses. |
|
|
|
|
8) Batliboy Turning Center |
|
With Hydraulic Indexing Chuck |
|
Suitable for machining of UJ Crosses. |
|
|
|
|
9) Special Purpose Machines. (05 Nos) |
|
SPM's (Drilling, Groving, Tapping) suitable for carrying |
|
different operations on UJ cross and other components |
|
|
| |
|
| |
|
| |
|
| |
|
| |
| |
|
 |
|
|
