Floline Corporation, promoted by a young enterpreneur over more than a decade ago is a trusted name in valve,Flanges & Fittings.We are serving the Process Industry in the country with a wide range of Quality assured products and services. Apart from standard designs we can also take up custom built products subject to Economical & Technical viability.

Apart from stringent in home stago inspection by qualified Engineers we can also offer IIIrd party inspection or clients Inspection for other products.

A wide range of standard valves, flanges & fittings are offered for Ex-stock to meet urgent requirements.

GENERAL TECHNICAL INFORMATION ON VALVES

Excellent work & proven design features are the very basis of the valves.standard
valves are with cast end pieces, bodies & bonnets. However on request valves are manufactured from rolled or forged bar stock materials as well.

CAST VALVES

Casting material conforms to relevant ASTM material specification. Casting are of highest quality, well proportioned and defect free with heat mark. Wall thickness are
of very liberal nature confirming to ANSI B 16:34 Material Test and heat treatment certificated are furnished to the client.

BAR STOCK VALVES

On request high pressure valve or tailor made valves are machined from Carbon Steel, Stainless Steel higher, Alloy materials bar stocks.

MATERIAL OF CONSTRUCTION

Cast, Carbon Steel, Stainless Steel & Cast Alloy, Nickel, Monel, Hastalloy B & C or any
other material as per the clients request.

END CONNECTIONS

Any of the following end connections are provided as may be suitable for
the clients requirement.

Flanged end	-	to ANSI B 16.5 RF with serrated finish
	-	to DIN standard 2532, 2533
	-	to British standard BS.10 Table D,E,F
Butt-weld ends	-	to ANSI B 16.25, B 16.9
Socket weld ends	-	to ANSI B 16.11
Screwed ends	-	to ANSI B 16.11 BSP, BSPT or NPT
Face to Face dimensions to ANSI B 16.10, BS 2080

RATINGS

ASA 150 # 300 # 800
DIN - PN - 10,16,25,40

SIZE RANGE

Flanged end : 15 mm to 600 mm
Screwed end : 15 mm to 50 mm
Welded end : 15 mm to 50 mm

INSPECTION

We manufactured under any third party inspection or clients own inspection
to their satisfaction.

TESTING

Each valve is hydrostatically tested as per ANSI B 16, 34, BS, DIN or Equivalvent codes as per the ratings, Pneumatic test is also offered.

SUGGESTING

While installing valve on a dirty contaminated systems install a strainer on upstream
side to minimize maintenance.
