Box Strapping Machine, Liquid Filling Machine, Conveyors Systems, Shrink Wrapping Machine, Stretch Wrapping Machine, Special Conveyor.
• Box Strapping Machine
• Liquid Filling Machine
• Conveyors Systems (Roller, Belt, Wire Mesh, Sleetes)
• Shrink Wrapping Machine
• Stretch Wrapping Machine
• Special Conveyor Etc.

STRAPSEAL SEMI AUTOMATIC STRAP SEALING MACHINE


Features :
• Innovative design for easy operation by Lay Man.
• Plug in any Outlet, Switch on & is Ready to Operate.
• Power Save mode activates when Machine is not in use.
• The Packing is Tamper Proof. It can pack any Size and Shape with heavy strength.
• We design as per specification.
• Simple adjustment for strap change over 6mm to 15mm.
• Stainless Steel Frame Cover available on special request.
• Easy to move and lift.

Specification :
Strap Cycle Speed : 1.5 sec. / strap
Tension Strength : 55 kg /max
Strap Width : 6 to 15 mm & 19 mm on request
Minimum Package Size : 60 mm(W)
Driving Motor : 250 W X 1(1/4 H. P. )
Dimensions : 900L x 600W x 750H (m/m)
Power Supply : 240 V 50Hz, 1 Phase
Sealing Method : Heat Sealed
STRAPSEAL SEMI AUTOMATIC STRAP SEALING MACHINE


STRAPSEAL SEMI AUTOMATIC STRAPPING MACHINE



Features:
• One touch and easy operation: turn the power on and you are ready to strap your packages. Motor stops automatically when not in use within preset 60 seconds to save energy and prolong motor life.

• Advanced P. C. B. control system : New Easy-to-Replace printed circuit board (PCB), controls feeding, tensioning, welding, sealing, cooling of strap welds as well as other functions of the machine for trouble-free and low-cost operations.

• Perfect Welding Heater Plate : One-piece die-cast nickel steel heater plate completely eliminates heater blade problems associated with other older style heater elements.

• Quality Electromagnetic Clutch Transmission : Durable electromagnetic clutch transmission increase motor life, strapping speed and reduces overall machine noise.

• Top Safety Concern : Safe 24VDC electrical control eliminates possibilities of electrical of electrical shock.

Specification :

Power Supply :1Ø, 220V, 50HZ
Driving Motor :1/4HP, 220V 200W
Dimension :910mm(L) x 580 (W) X 730mm (H)
Strap Width :6-15mm
Strapping Speed :1.5 sec/strap		 Min. Package Size :60mm
Max. Package Size :Any Size
Weight :100 Kg
Sealing Method :Heat Sealing
STRAPSEAL SEMI AUTOMATIC STRAPPING MACHINE


SEAL N SHRINK TUNNEL TYPE MACHINE


  CHAMBER TYPE MACHINE
Features:
• Seal N Shrink - Chamber Type Machine used in all Industries
• Printing & Packaging Books, Manufacturer of Food Products
• Manufacturer of Rubber, Textile, Confectionery, Adhesive etc.
• Sealing Area : As per product specification.
• Power Consumption depends upon the products and film which is used to shrink
• Tunel Conveyor, Roller wire mesh, Belt.		 CHAMBER TYPE MACHINE
SEAL N SHRINK TUNNEL TYPE MACHINE

FULLY AUTOMATIC STRAPPING MACHINE

Features:
• Aluminum Arch - all in one design. Easy to increase the width or the height, only add some parts to the original.
• The guide of the brush is a big help to strap the package at the proper postion. Brilliant performance.
• Make operation easy, time saved, labour savings.
• The advance P. C. B. microchip circuit board control system, less malfunction and easy maintenance
• Tension Adjustments : Can be adjustable at will, Max tension is over
• 90 kgs, suitable for various kinds of cartons to choose the tight or loose strap. The strap never fall off.
• Precision Structure: Main machine's component is made of aluminum alloy. Control system is compatible.
• Easy loading or unloading: To load or unload the strapping roll is convenient due to the dispenser is placed outside

Specification :
Power Supply :230, 415 V, 50 HZ
Arch Size :W850 x H600 mm (Standard)
Strap Width :9.12, 15.19 mm
Strap Tension :Max. 90 kgs		 Strapping Speed :2.4 sec/strap
Weight :250 kgs
Size :L1460 x W606 x H1521 mm

FULLY AUTOMATIC STRAPPING MACHINE

PLUG PRESSING MACHINE
PLUG PRESSING MACHINE


BOTTLE FILLING MACHINE / PISTON TYPE
LIQUID FILLING MACHINE
BOTTLE FILLING MACHINE Bottle Filling Machine is designed to fill various types of liquids such as pesticides, soft drinks, beverages, syrups, adhesives and any types of liquids. It can also be used to fill semi-solid liquids. Syringes (Piston Type) is used to measure the liquids in correct volumetric and send it to the bottles.
Ranges of Syringe : 30 ml., 110 ml., 260 ml., 550 ml. & 1000 ml.
Filling Heads :2, 4, 6 & 8 Nozzles.		 LIQUID FILLING MACHINE

We are manufacturing conveyor systems as per customer requirement like Roller Conveyor, Wire Mesh, Belt and Sleete Conveyor,Teflon MS/SS
SLEETE CONVEYOR ROLLER CONVEYOR
SLEETE CONVEYOR
ROLLER CONVEYOR
  We deal with Strapping rolls, polyolefin, Shrink Film,
Stretch Film, BOPP Tape, Cling Film & PVC, LDP, Pouches & Rolls.

K-121/122, Udyog Vihar Indl. Estate, Vitthalwadi Station (W), Dist. Thane- 421003. Telefax (F) : 0251-2549698, Mobile : 9820141565, 9820303030 Website : www.strapseal.com
Email : [email protected]
