Spring Balancer, Air Hose Balancers, Air Hose Reel, Overhead Trolleys, Water Hose Reels, Grease Hose Reels, Oil Hose Reels, Polyurethane Tubes, Electric Reels, Mumbai, India
      Profile................

MAHESH INDUSTRIES was established in the year 1996 primarily for the manufacturers and suppliers of Spring Balancers, Air Hose Balancers, Air Hose Reel, Oil Grease, Water Hose Reel, Electrical Hose Reels, P. V. Coiled & P. V. Tubes, for hydraulic and pneumatic equipments. We believe in providing quality to our clients with deliveries at the most competitive prices. We believe in setting standards and moving head with the times.

The company has successfully developed variety of hydraulic & pneumatic equipments over the year as result of continuous efforts and enterprises thereby providing solution to Engineering Industrial problems.

The company is headed by Mr. Mahesh Mistry and Mr. Mayur Rana and a team of qualified persons having vast experience in the respective disciplines.

MAHESH INDUSTRIES is known for its prompt service to the customers by designing & developing new industrial products to suit specific applications.

    Product..................

Light Spring Balancer

Light Spring Balancer

Features

  • Quick installation

  • Heavy duty spring

  • Easy tension adjustment-no tools required

  • Durable nylon converted steel rope

  • Convenient snap type tool hook

  • Inline alignment of hanger & tool hook

  • Ergonomic design, user friendly



Ratchet Balancer
Ratchet Balancer


Spring Balancer with ratchet mechanism to stop the wire under no-load condition also to attach or detach the tool easily. The ratchet wheel is fixed to the tapered drum and spring case. When the ratchet works by operating lever clutch the wire is at a standstill and when the ratchet is released the wire moves up and down.

Specifications


Model No. Balancing Capacity Travel
  Min Kgs Max Kgs (Mtrs)
MSB - 9.0R 4.5 9.0 1.3
MSB -15R 9.0 15 1.3
MSB -22R 15 22 1.7
MSB -30R 22 30 1.7



 Overhead Trolleys
overhead trolleys

“MI” I-BEAM Trolleys has been designed specially to be used along with Spring Balancers in weld shop of automobiles on standard I- Beam ( 150 X 75 ) or ( 200 X 100 ) or ( 125 X 65 ) for 3 dimensional movement on X-Y-Z axes.  These trolleys are made from steel side plates graded cast iron rollers.  This trolleys are rugged in construction and comes with good quality rollers bearing, steel shafts and nitrile rubber shock absorbers and power coated for food surface finish.  These trolleys are available in 4 models for suspending transformer, Welding Gun and Kick less Cable

Specifications
Model No. Capacity Min radius for curve Available beam Mass
MIOT – 01 1000 Kgs 1500 mm 15 X 75 X 5.5 mm 13 Kgs
MIOT – 02 500 Kgs 1000 mm 75 X 150 X 5.5 mm 6.5 Kgs
MIOT - 03 250 Kgs 1000 mm 150 X 75 X 5.5 mm 6 Kgs

Air Hose Balancer
Air Hose Balancer

       Features

  • Quick installation.Heavy Duty Spring

  • Easy Tension Adjustable

  • Durable P. U. Tube with brass fitting for tools

  • Inline Alignment of integers







    Specification


Model No. Hose Balancer capacity Max working Working Pressure
  ID X OD (mm) Min. Kgs Max. Kgs Length of tube (Kg/cm2)
MABT - 1 8 x 12 0.5 1.0 1.5 m 10 Kg/cm2
MABT - 2 8 x 12 1.0 2.0 1.5 m 10 Kg/cm2
MABT - 3 8 x 12 1.0 3.0 1.5 m 10 Kg/cm2
MABT - 5 8 x 12 2.5 5 1.5 m 10 Kg/cm2
