SAFETRACK

Safetrack insulated conductors are designed in accordance to international regulations for multitude of power supply applications.

These conductors are compact, insulated, easy to install, in horizontal or vertical
configuration. They require much less space compared to conventional bare conductor systems.

The conductor bars are 4 meters long to be supported at every 1 metre, effecting
considerable savings in installation. Conductors are easily assembled at site with the
use of a jointing tool. All bars are supplied with connecting pins.

Design allows uni/multi pole mounting arrangement. Conductors can be mounted side
by side min. centre distance 30 mm.

Factor made curved conductors available.

Galvanised iron conductor - rated 100A / 125A
Copper conductor - rated 250A/315A
S.S. Conductor - rated 40A

MOUNTING

Insulated hanger clamps support conductor. Standard mounting brackets available or
designed for specific requirement.
The conductor can be mounted horizontally or vertically.
No minimum clearance required with other structures.

FEED TERMINALS

The power feed point can be at the ends or anywhere along the run. One or more power
feed point positions possible to reduce voltage drop.
Feed terminal clamps should preferably be installed at rail joints.
END CAPS
The open ends / end feeds of condutors are covered by end caps.

COLLECTOR

A fully articulated sliding type collector assembled from strong, purpose designed,
glass filled nylon moulding. This design produces compact unit fully insulated from
the support bracket.
S.S Spring ensures adequate contact pressure.

EXPANSION JOINTS

In order to accomodate the effects of temperature change, it is necessary to provide
expansion joints, where system run exceeds 200M-G.I. and 150 M- Copper.

INSTALLATION

Safetrack can be installed in most type of atmospheres such as dirty, dusty, acidic,chemical etc.
No crane gantry is perfectly free or level, Safetrack acknowledges this fact by designing
adequate lateral/vertical tolerances on collector.
Suitable for outdoor applications also.

MAINT.COST

Only consumable item is contact shoe. No periodic maintenance required.
ADVANTAGES OVER ANGLE IRON CONDUCTOR SYSTEM

1. It is insulated.
2. It is finger safe.
3. It is accident free.
4. It is colour coded R Y B G.
5. No protection guard required.
6. It is compact occupies less space.
7. No sparking - spring loaded current collector provide pressurised electrical contact.
8. It is better resistant to atmospheric conditions. For severe conditions S.S. Conductor
available
