:: IMPACT TESTING MACHINE ::

Charpy Test
The Charpy test piece rests on alloy steel support anvils, fitted on the base of the machine rigidly held in position by Allen screws. End stopper is provided for quickely and accurately locating the test piece centrally between the supports.

Impact Testing Machine

Izod Test

The Izod test piece is clamped vertically in Izod support fitted on the the base of the machine. The support is provided with a machined vertical groove to suit the test piece size. The front clamp piece & the Allen screw enable clamping of the test piece incorrect heigh with the help of Izod setting gauge supplied.

Model : IT - 30 (ASTM)

The Impact tester offered with 300J energy exclusively for Charpy test confirming to ASTM E-23. This machine is geometrically checked in the works to the more stringent requirements of the American standard. The accuracy of the machine is then vertified by PROOF TEST by testing standard test specimens supplied by the NIST, USA. All two sets of the five specimen must agree with the normal values within certain tolerance specified.

Technical Specifications

MODEL	AI-IT 30	AI-IT30 D	AI-IT - 30 (ASTM) CHARPY TEST	AI-IT 1.5	AI-IT 0.5
Maximum Capacity	300K / 168 J	300J / 170 J	300 J	15 J	5 J
Minimum Scale Graduation	2 J	0.5 J	2 J	0.1 J	0.05J
Overall Size (Approx)	1.1 m x 0.45 mx 1.65m (H)	1.32m x 0.45 mx 1.65 m (H)	1.4 m x 0.5 m x 1.9 m (H)	0.5m x 0.3m x 0.52m (H)	0.5m x 0.3 m x 0.52 m (H)
Net Weight	375 Kg.	375 Kg.	450 kg.	70 Kg.	70 Kg.

Optional Accessories For AI-IT 30 / AI-IT 30 (D)

• Izod support for 0.45" dia Izod round specimen.
• Self centering tong for quick and accurate setting of Charpy test specimen.
• 'V' notch milling cutter
• 'U' notch milling cutter
• Caliper guage for checking V notch for Izod & Charpy.
• Templates for checking 10 x 10mm. cross secion of Izod / Charpy test specimen.
• Depth notch guage including V & U notch gauge for checking depth below V U notch, angle and radius.

Top

HARDNESS TESTING MACHINE


AI-RAS	AI-RAB 250	AI-TWIN

• FEATURES OF HARDNESS TESTER

Hardness Testers Models AI-RAS, AI-RASM, AI-RABI, AI-RAB250, AI-TWIN are manually operated. All these models are suitable for testing hardness of metals and alloys of all kinds hard or soft, whether flat, round or irregular. These are simple in design and easy to operate. Yet sensitive and accurate. Various models from the wide range are suitable for Eng Colleges, labs, Tool Rooms, Inspection Dept. These testers strictly conform to IS:1586-2000, BS:891 parts 1 & 2 ASTM: E18 for Rockwell Test IS:2281-1983, BS 240, ASTM E 10 for brinell Test and IS 1586-2000 ASTM E18 for Rockwell Superficial Test

• ROCKWELL HARDNESS TESTER

MODEL : AI RAS
Automatic load selection with automatic zero setting dial gauge Manual Operation.

MODEL : AI RASM
Similar to ‘AI RAS’ but motorised model. Semiautomatic operation for production testing. Drive motor single phase 230 v 50 cycles

• ROCKWELL CUMBRIVELL HARDNESS TESTER

Model : AI-RABI
Automatic load selection with automatic zero setting dial gauge. Facility for Brinell Tests with 187.5 kgf. Load with 2.5 mm ball indenter, additional load 250 kgf. With 5 mm ball indenter for testing hardness of non-ferrous metal. Manual Operation.

MODEL : AI-RAB 250
Similar to AI-RABI but bigger capacity Diamond Holder is guided in a set of two ball cage, which enables testing of small pins having dia. Less than 6 mm (upto 3mm dia)

• ROCKWELL CUM ROCKWELL SUPERFICIAL HARDNESS TESTER

MODEL : AI TWIN
Manual load selection with automatic zero setting dial gauge. Manual Operation. Diamond Holder is guided in a set of small pins having dia. Less than 6 mm. (upto3 mm dia.)

Top

VICKERS HARDNESS TESTER
MODEL AI VM 50

Vickers Hardness Tester

ROCKWELL MOTORISED ELECTRONIC
HARDNESS TESTING MACHINES

Rockwell Hardness Tester (Electronic)

:: Torsion Testing Machines ::

Application & Operation

Torsion Testing Machine is designed for checking torsional property of various metal wires, tubes, bars etc.

Trque applied to the specimen is transferred to measuring dial through lever mechanism. Torque is measured by Pendulum Dynamometer system. Torque range can be adjusted by adding weights. Geared motor is used to exert required torque at other end of specimen. Auto-graphics Recorder gives the relation between Torque and Angle of Twist. These machines are calibrated as per latest IS standards.
Calibration is within ±1% operation range of all models.

Technical Specification :

MODEL		AI- TT-10	AI- TT-20	AI- TT-50	AI- TT-100
Capacity Nm	Nm	100	200	500	1000
Torque Ranges	Nm	20,50,100	50,100,200	50,100,250,500	100,250,500,1000
Divisions on Dial	Nos.	500	500	500	500
Test Speed	RPM	0.5	0.5	0.5	0.5
Clearance Between grips	mm.	0-420	0-450	0-500	0-600
Grips for Round Specimen Dia	mm	4-8 8-12	7-10 10-15 15-20	10-17 17-24 24-30	10-18 18-28 26-30
Grips for Flat Thick Specimen Width	mm	2-8 25	3-10 30	2-12 40	5-15 50
Power Requirement 415 V, 50hz, 3Phase	kW	0.25	0.25	1.0	1.0
