Products :- |
| |
| Wear Parts : |
|
• |
Engineering |
-
Work rest blades, Lathe centers
- Surface gauges, Seal rings |
• |
Razor Blade, Cigarette, Jute, Textile Industries |
-
Conveyor and guide parts |
• |
Instrumentation |
-
Checking Pointers, Slip / Plain
Gauges |
|
| |
•
Mining Tool Inserts |
DTH Button bits, Drill Steel rods,
Rock Roller bits, Coal Auger tips |
|
|
| |
|
•
Mining Tool Inserts |
For Ferrous, non-ferrous, wood,
bakelite, textile, plastic and
many other materials. |
|
|
| |
|
•
Healing and Wire drawing |
|
Forging of nails, screws, rivets,
steel balls. Wires and bar drawing. |
|
| |
|
•
Tungsten Copper |
|
Electrodes for EDMs, Electrical contacts for
switchgear. |
|
| |
|
|
| |
DIAMOND
/ CBN WHEEL SELECTION AT A GLANCE : |
| |
Grit Selection |
Grit
Size : (Mesh) |
Expected
Surface
Finish (Rms) |
Rough |
80 |
100 |
120 |
26 |
22 |
17 |
Medium |
150 |
220 |
-- |
15 |
11 |
-- |
Fine |
320 |
400 |
-- |
8 |
7 |
-- |
Super
Fine |
500 |
600 |
1200 |
6 |
5.5 |
3 |
|
| |
|
|
Grit
Size of Diamond Wheel |
Depth
of Cut |
#
80 - 120 |
Within
0.03 |
#
140 - 200 |
Within
0.02 mm |
#
230 and finer grits |
0.01
mm & Less |
|
RESIN
BOND :
Mostly dry grinding. High Material Removal Rate, Free Cutting Action
Lesser heat,
Economical in use, |
|
CONCENTRACTIONS
:
It is available in 25, 50, 75, 100, 125 & 150.
For General purpose 50 & 75 Concentractions are recommended. |
|
DEPTH
OF IMPREGNATION : |
It
is available in 1.5 mm, 3.0 mm, 5.00 mm, 10 mm.
Higher the DEPTH OF IMPREGNATION Higher the economy. |
|
HOW
TO ORDER : PI. Mention following details. |
1.
Shape |
2.
Specifications
Diameter x Thickness x Hole ( Bore ) x Face width |
3.
Bond |
4.
Concentration. |
5.
Grit Size. |
6.
Depth of Impregnation. |
|
| |
|
|
|
|
